• Dual-Radio Concurrent 2.4 GHz & 5 GHz ( 802.11 ax/n/b/g)
  • Manageable by InControl 2 – one-stop platform to manage the entire WLAN network
  • Plenum Rated, Indoor Plastic

Click here for product datasheet

SKU: APO-AX Categories: , Tag:


Better Coverage and Speed with Wi-Fi 6

Deploy Anywhere, Manage Centrally, Turnkey or Custom Captive Portals, Enterprise-Grade Fast Roaming, Seamless Peplink SD-WAN Integration.

Product Code APO-AX
Ethernet Port 1x 2.5 Multigigabit Ethernet
Wi-Fi Standard 1x 2.4Ghz 802.11b/g/n/ax
1x 5Ghz 802.11a/n/ac/ax
Data Rates 4X4 MU-MIMO
2.4 GHz: up to 1148 Mbps
5 GHz: up to 2400 Mbps
Channel Width 20/40/80 MHz
Recommended Concurrent
Users per Radio
SSID Per Radio 16
Transmit Power 2412 – 2472 MHz: up to 17dBm
5180 – 5825 MHz: up to 17dBm
Included Antenna Built-in Omni Antenna
Antenna gain: 5dBi for 2.4GHz,
5dBi for 5GHz
Enclosure Plenum-rated,
Indoor Plastic
Dimensions 8.1 x 8.1 x 1.3 inches
205 x 205 x 32 mm
Weight 1.73 pounds
785 grams
Power Input DC Jack: 12V DC
AC Adapter: AC Input 100V − 240V, DC Output 12V, 3A*
802.3at PoE #
Power Consumption 24W (max.)
Operating Temperature 32° – 104°F
0° – 40°C
Certifications FCC, CE, RoHS
Warranty 1 Year Limited Warranty


* Optional feature.
#PoE Injector is available separately.
