• Industrial-Grade M2M 4G Router
  • 1x Embedded 4G LTEA Modem (Americas/EMEA)
  • 1x Ethernet WAN
  • GPS/Fleet Tracking
  • Full antenna set

Click here for product datasheet

Recommended antenna: Mobility 20G


SKU: MAX-BR1-ENT-LTEA-D-T Categories: , Tag:


Ethernet WAN Ports 1 (GE)
Ethernet LAN Ports 2 (GE)
Embedded 4G LTE 1
Cellular Modem @ LTE / LTE-A
Redundant SIM Slots Yes (( Mini-SIM (2FF))
USB WAN Modem Port 1
Recommended Users 25-150
Router Throughput 300Mbps
PepVPN Yes
SpeedFusion Hot Failover Yes
SpeedFusion WAN Smoothing Yes
Drop-in Mode Yes
Number of PepVPN SpeedFusion Peers 2/5/20 (!)
PepVPN/SpeedFusion Throughput (No Encryption / 256-bit AES) 100 / 60 Mbps
802.1q VLANs Supported 16
IP Passthrough Yes
High Availability Yes
WAN as LAN Yes
Web Filtering Blacklist Lite
Power Output 802.3af PoE Output*
AC Adapter AC Input 100V-240V
DC Output 12V, 2A
Power Input | Terminal Block DC 10V-56V 2A
Power Consumption Max.: 16W, Typical: 11W, Min.: 8W
Dimensions 1.6 x 5.8 x 5.0 inches |
40 x 147 x 128 mm
Weight 0.96 pounds |
435 grams
Operating Temperature -40° – 149°F |
-40° – 65°C
Certifications -FCC, CE, RoHS, E-Mark, IC
-RF Port Lightning Immunity: ITU-T K.20 (+/- 1.5 kV)
Warranty 1-Year Limited Warranty

@ LTE-A option: 300Mbs / 50Mbs available. (LTE option: 100Mbs / 50Mbs)

(!) 2 PepVPN Peers are enabled by default. Can be increased to 5 Peers using license PVN-LC-05 or to 20 Peers using license MAX-HD-020-SPF.

* Optional PoE Activation Kit is required to activate 802.3af PoE Output.
